Description
This versatile device also does not cut short on comfort and ergonomics. It features an arched frame to serve as a carry handle and packs a 1050mAh rechargeable battery for 2 hours of uninterrupted cordless operation. To provide enough room for movement, its sturdy polymer stage is extra wide (4.4 x 4.4″) and offers two pre-loaded metal clips for securing your specimens. Using the knob on the right, you can move the stage up or down to reach an ideal sharpness of focus and then lock it with the left knob.
CMOS Sensor
- 5.0MP CMOS sensor
- Captures 5.0, 3.0, and 1.3MP images, and 12.0MP interpolated images.
- Records 5.0MP videos at 30 fps
- Shutter speed from 1/1000 to 1 seconds
TFT LCD Display
- 3.5″ color LCD display
- 320 x 240 resolution
-
4x onscreen digital zoom
Optical System & Illumination
- 2 – 160x optical magnification
- 800x magnification using digital zoom.
- 5-element infrared-reducing glass lens system
- Effective focal length is 15.8mm
- Focusing range of 0.4″ to infinity
- Low 0.1% image distortion
- Top 8-LED illumination ring with adjustable brightness
Construction Details
- Full-sized polymer frame
- Ergonomic body design
- Focusing wheel is located on the optics module.
- Stage lock knob is located on the left side of the frame.
- Stage height knob is located on the right side of the frame.
- Arched frame can serve as a handle.
- Specimen stage allows 0.4″ height adjustment.
- Two pre-loaded metal clips for holding slides.
- Built-in shutter control on base
- Rechargeable 1050mAh battery allows cordless operation for 2 h
- Mini-USB port for PC connectivity
- Video out AV port
