| CAMERA IMAGE SENSOR |
|
| Sensor |
1.0 Inch-type CMOS |
| Filter |
RGB Primary ColourFilter |
| Total pixels |
Approx. 13.4 MP |
| Effective pixels |
Approx. 8.29 MP (3840 x2160) |
| Image Processor |
DIGIC DV7 |
| Gain Boost Function |
Yes, increases gain to 36dB,activated via user assigned button |
| Sensitivity (PAL) |
f/13, 50.00P, 2000 lux, reflectance89.9% |
| Minimum illumination (PAL) |
50.00P/50.00i Approx. 2.5 lux (1/50 second shutter speed)
25.00P Approx. 1.3 lux (1/25 second shutter speed) |
|
|
| LENS |
|
| Zoom ratio |
15x optical, (30x Advanced Zoom Full HD) |
| Focal length (35mm equivalent) |
Approx. 25.5 to 382.5 mm Standard IS/IS Off |
| Minimum focus distance |
10 mm at wide end, 60 cm across entire zooming range |
| Max. Aperture |
f/2.8 |
| Aperture blades |
9 blades |
| Filter diameter |
58mm |
| Image stabilization system |
Optical system (lens shift) + electronic stabilization
Dynamic, Standard, Powered, Off |
| ND filter |
3 densities: turret switched, motor-driven.
ND 1/4, ND 1/16, and ND 1/64. |
| Zoom control |
Zoom rockers on body and handle;
Selectable manual zoom/focus ring on lens;
Wireless controller; Selectable High-Speed mode available. |
| Zoom speed |
Variable or Constant speed Fast/Normal/Slow, 16 speed level settings |
| Focus control |
MANUAL: Lens ring and touchscreen point selection (Focus Guide and Peaking assist functions), Focus Preset.
AUTOFOCUS: Touchscreen AF point selection, Face Detection and Tracking, Face Only AF.
(Continuous AF, AF-Boosted MF, AF Speed, AF Response, AF Frame size) |
| Focus System |
Dual Pixel CMOS AF, Contrast AF, Eye AF, EOS iTR AF X |
| Iris control |
Touchscreen, Auto, Lens ring |
| Digital zoom/Teleconverter |
300x Digital Zoom, Digital Teleconverter (x1.5/x3/x6. Not available when optical teleconverter used) |
|
|
| Image Processor |
|
| Type |
DIGIC DV7 |
| Colour Sampling |
XF-AVC: 4:2:2,
MP4: 4:2:2 or 4:2:0 H.265/4:2:0 H.264.
XF-AVC/MP4 Proxy files: 4:2:0 |
| Bit depth |
XF-AVC/MP4 H.265: 10-bit.
MP4 H.264: 8-bit
XF-AVC/MP4 Proxy files: 8-bit |
|
|
| RECORDING |
|
| Video storage media |
SD/SDHC/SDXC card (2 card slots) |
| Type |
Class U3 V90 cards recommended |
| Recording time (128GB Card, approx.) |
XF-AVC: 410Mbps. 39 mins. 310Mbps, 51 mins. 260Mbps, 100 mins.
MP4/H.265: 225 Mbps, 71 mins. 170Mbps,94 mins. 135 Mbps,118 mins
MP4/H.264: 150 Mbps, 107 mins. 35 Mbps, 458 mins. 8Mbps, 2006 mins |
| Recording file system |
FAT32/exFAT |
| Internal recording format (PAL) |
XF-AVC (MXF) UHD: ALL-I/Long GOP. Full HD/Proxy Files: Long GOP
MP4: H.265 UHD, Full HD |
| Variable Frame Rates |
to 120 fps |
| Gamma Curve |
Canon Log 3, HDR-HLG |
| Audio Recording |
2-Channel 16-Bit 48 kHz AAC Audio
4-Channel 24-Bit 48 kHz LPCM Audio |
| Still Image Support |
JPEG
2 MP (1920 x 1080) |
| IP Streaming |
MPEG2: 1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.00 Mb/s)
MPEG2: 1920 x 1080 to 1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s) |
|
|
| Interface |
|
| Media/Memory Card Slot |
Slot 1: SD/SDHC/SDXC
Slot 2: SD/SDHC/SDXC |
| Video Connectors |
1 x HDMI (HDMI 2.0) Output
1 x BNC (12G-SDI) Output |
| Audio Connectors |
2 x 3-Pin XLR Input
1 x 1/8″ / 3.5 mm Stereo Input
1 x 1/8″ / 3.5 mm Stereo Headphone Output |
| Built-In Microphone Type |
Stereo |
| Other I/O |
1 x USB Type-A Output
1 x USB Type-C
1 x BNC Genlock, Sync Input/Output
1 x BNC Timecode Input/Output
1 x 2.5 mm Control
1 x 8-Pin D-Sub Control
1 x RJ45 LAN Input/Output |
| Wireless Interfaces |
2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control |
|
|
| Monitor |
|
| Size |
3.45″ |
| Resolution |
2,760,000 Dot |
| Display Type |
Articulating Touchscreen LCD |
|
|
| EVF |
|
| EVF |
Attached |
| EVF Display Type |
OLED |
| Screen Size |
.36″ |
| EVF Resolution |
1,770,000 Dots |
|
|
| Power |
|
| Battery Type |
Canon BP-A Series |
| Power Connectors |
1 x Barrel (24 VDC) Input |
| Power Consumption |
21.5 W |
|
|
| Environmental |
|
| Operating Temperature |
0 to 40°C |
| Operating Humidity |
0 to 85% |
|
|
| Physical |
|
| Accessory Mount |
1 x Cold Shoe Mount
1 x Multi-Interface Shoe |
| Tripod Mounting Thread |
1/4″-20 Female
3/8″-16 Female |
| Built-In Light |
Yes (Infrared) |
| Dimensions |
385 x 219 x 210 mm (With Protrusions)
333 x 173 x 168 mm (Without Protrusions) |
| Weight |
2010 g |
